Light source：784 0.5W 5050 RGB 3-in-1 LEDs + 196 2W white LEDs (White)
Color temperature: 2800K-8000K
Dominant wavelength R：622nm；G：525nm；B：457nm
Light source lifetime： 20000 hours
Beam Angle： 110°
Dynamic effect
stroboscopic： 0～20Hz
Four dimming curves，0 ~ 100% dimming
Electronic parameter
Input voltage and frequency 100～240VAC,50～60Hz
Power Fully bright 700W，stroboscopic 1200W
Waterproof POWERCORN Input, output
Signal connection Waterproof 3-core DMX signal line input/output, the maximum number of connections 32 units; Waterproof network signal input and output
Working environment -10°～45°
Switching power supply 100～240VAC, 50～60Hz,28V 800W
Structural parameter
Dimension Product size：540×338×152mm
Net weight: 10.0Kg(without hook and hook quick lock)
Class of protection IP65
Cooling system Waterproof, low noise fan, forced heat dissipation
shell Die casting magnesium aluminum alloy; black
Installation mode: Side hanging, hanging installation
Controls
Control mode DMX512/RDM
DMX passage 8/11/13/24/30/74/97CH
reveal TFT
Refresh rate 600Hz/1200 Hz/2000 Hz/4000 Hz/6000 Hz/25KHz
Pixel matrix White light 2*14, color light 2*7
